Jonge Poerink Conveyors

KPA-KRM

KPA-KRM conveyor
KPA-KRM conveyor
KPA-KRM conveyor
KPA-KRM conveyor
KPA-KRM conveyor
KPA-KRM conveyor

KPA-KRM

The strong, straight, all-round conveyor.

With the KPA KRM, Jonge Poerink Conveyors offers a reliable, high quality conveyors which can be used in many different industries.
Our plastic belts are suitable for conveying large numbers of products. Because of the chemical resistance, they are suitable for both packaged and unpackaged food, for example dairy, meat, processing and canning industry. The plastic belts are easy to clean and do not require lubrication. They are also durable and quiet.

KPA 30
Belt Type KPA 30 is a Plastic panel (modular) conveyor belt that has been developed for the treatment of different products. The belts are suitable for almost all industries, especially in the process industry. The material of the belt of fiberglass reinforced polyamide with high abrasion resistance and high chemical stability. Because the hinge space between the panels is extremely small, the KPA 30 has a smooth, closed belt surface.



KRM 50
KRM 50 panel belt has a large open area of 60%. The panels have a thickness of 10 mm, a belt division of 50 mm and the inserts are made of stainless steel. The insert is slightly shorter than the total width of the belt and secured by small plastic pins, fitted in the insertion openings in the outer panels. The material is acetal (POM), or glass-fiber reinforced polyamide witch is high abrasion resistance and has a high chemical stability.

Specifications

KPA-30
Frame material: Mild Steel or Stainless Steel
Belt pitch: 30 mm
Rod diameter: 4 mm
Rod material: Stainless Steel 1.4301
Panel material: Acetal (POM), Glass fibre reinforced Polyamide (PA)
Panel thickness: 9 mm
Belt width: minimum 100 mm (steps of 100 mm)
Allowed belt load: 1850 kg/meter belt width
KRM-50
Frame material: Mild Steel or Stainless Steel
Belt pitch: 4 mm
Rod material: Stainless Steel 1.4301
Panel material: Acetal (POM), Glass fibre reinforced, Polyamide (PA)
Panel thickness: 10 mm
Belt width: 100 mm (steps of 100 mm
Allowed belt load: 1850 kg/meter belt width
